Product Details:
|
Name: | OPzS Battery | Model: | OPzS |
---|---|---|---|
Voltage: | 2V | Capacity: | 800ah |
Terminal: | F12 | Color: | Black,Gray,Customized |
Feature: | Low Self Discharge | Application: | Telecom,Electric Utilities,Security Systems |
High Light: | F12 Terminal OPzS Tubular Battery,2V800ah OPzS Tubular Battery,Low Self Discharge OPzS Tubular Battery |
Flooded lead acid battery 2V800ah OPzS Tubular Battery With F12 Terminal for solar system
OPzS series batteries
The OpzS Series is a traditional tubular plate flooded battery which offers 20+ years design life according to the standard
IEC60896-11. With a new design and technical improvement, it offers maximum efficiency and reliability for the widest varity of
applications. This series is highly suitable for all standby power applications that require the highest levels of reliability and
security.
>Main Features
1. OPzS battery series is Valve Regulated Lead Acid battery adopting immobilised GEL and Tubular Plate technology,
offering high reliability and stable performance.
2. The OPzS battery series is designed and manufactured according to DIN standards, with die-casted positive grid and patented active
material formula, they exceed the DIN standard values.
3. They offer 20 years design life in float service at 25"C and are more suitable for cyclic use under extreme operating conditions.
4. Suitable for power supply in telecommunication, photovoltaic wind energy storage and UPS applications.
Voltage | Voltage | Capacity | Internal resistance(mm) | Terminal Type |
Dry Weight (Kg) |
Wet Weight (Kg) |
|||
(V) | (Ah) | Length | Width | Height | Total Height | ||||
OPzS 200 | 2 | 200 | 103 | 206 | 355 | 410 | F12 | 13 | 17.5 |
OPzS 250 | 2 | 250 | 124 | 206 | 355 | 410 | F12 | 15 | 20.5 |
OPzS 300 | 2 | 300 | 145 | 206 | 355 | 410 | F12 | 17.5 | 24 |
OPzS 350 | 2 | 350 | 124 | 206 | 471 | 526 | F12 | 21 | 28 |
OPzS 420 | 2 | 420 | 145 | 206 | 471 | 526 | F12 | 23 | 32 |
OPzS 490 | 2 | 490 | 166 | 206 | 471 | 526 | F12 | 26.5 | 37.5 |
OPzS 600 | 2 | 600 | 145 | 206 | 646 | 701 | F12 | 35 | 47 |
OPzS 800 | 2 | 800 | 191 | 210 | 646 | 701 | F12 | 48 | 64 |
OPzS 1000 | 2 | 1000 | 233 | 210 | 646 | 701 | F12 | 58 | 78 |
OPzS 1200 | 2 | 1200 | 275 | 210 | 646 | 701 | F12 | 68 | 92 |
OPzS 1500 | 2 | 1500 | 275 | 210 | 796 | 851 | F12 | 80 | 111 |
OPzS 2000 | 2 | 2000 | 397 | 212 | 772 | 827 | F12 | 110 | 152 |
OPzS 2500 | 2 | 2500 | 487 | 212 | 772 | 827 | F12 | 132 | 185 |
OPzS 3000 | 2 | 3000 | 576 | 212 | 772 | 827 | F12 | 159 | 222 |
1. Applications
2. Telecom
3. Security Systems
4. Medical Equipments
5. UPS systems
6. Railroad Utilities
7. Photovoltaic Systems
8. Renewable Energy System
Component | Positive plate | Negative plate | Container | Cover | Separator | Electrolyte | Safety valve | Terminal |
Raw material | Lead dioxide | Lead | ABS | ABS | PVC-SiO2 | Sulfuric acid | EPDR | Copper |
>Competitive Advantage
1. Sealed construction,safty and no leakage;
2. Maintenance-free,convenient for installation;
3. Broad operating temperature range;
4. High capability,high energy density;
5. Low self-discharge tate,more deep cycle times;
6. Long service life,excellent recharge and discharge time than other batteries.
