Product Details:
|
| Name: | Sealed Lead Acid Battery | Model: | FBR12-65 |
|---|---|---|---|
| Voltage: | 12V | Capacity: | 65AH |
| Terminal: | F14 | Dimension: | 350*167*175mm |
| Weight: | 20kg | Color: | Light Gray, Cutomized |
| Feature: | Low Self Discharge | Application: | EPS And UPS Battery Backup |
| Electrolyte: | Acid Battery | Battery Type: | Deep Cycle, Sealed Gel |
| Rechargeable: | Chargeable | Origin: | Made In China |
| HS CODE: | 8507200000 | Trademark: | FOBERRIA |
| Material: | ABS | ||
| High Light: | F14 Terminal Sealed Lead Acid Battery,EPS 12V Sealed Lead Acid Battery,65Ah Sealed Lead Acid Battery |
||
AGM sealed lead acid batteries 12V65Ah vrla sealed lead acid battery F14 Terminal
| Battery Model No. | FBR12-65 | |
| Nominal Voltage | 12V | |
| Capacity | 20HR(5.25V) | 65Ah |
| (25ºC) | 10HR(5.25V) | 57Ah |
| 1HR(4.80V) | 40Ah | |
| Dimension | Length | 350±2mm |
| Width | 167±2mm | |
| Height | 175±2mm | |
| Total height | 175±2mm | |
| Approx. Weight | 20kg±4% | |
| Terminal type | F14 | |
| Internal resistance | Approx 6mΩ(Fully charged,25ºC) | |
| Capacity affected by | 40ºC | 102% |
| Temperature(20HR) | 25ºC | 100% |
| 0ºC | 85% | |
| -15ºC | 65% | |
| Self-discharge(25ºC) | 3month | Remaining Capacity:91% |
| 6month | Remaining Capacity:82% | |
| 12month | Remaining Capacity:65% | |
| Nominal operating temperature | 25ºC±3ºC(77ºF±5ºF) | |
| Operating | Discharge | -15ºC-50ºC(5ºF-122ºF) |
| temperature range | Charge | -10ºC-50ºC(14ºF-122ºF) |
| Storage | -20ºC-50ºC(-4ºF-122ºF) | |
| Float charging voltage (25ºC) |
13.5 to 13.8V Temperature compensation:-18mV/ºC |
|
| Cyclic charging voltage (25ºC) |
14.5 to 15V Temperature compensation:-30mV/ºC |
|
| Max charging current | 19.5A | |
| Max discharging current | 650A(5sec.) | |
| Designed floating life(20ºC) | 10years | |
> Main Features
1. No memory effect
Some Sealed Lead Acid batteries say nickel –cadmium batteries will become conditioned to provide less power offer repetitious
short usage /discharge.
2. Maintenance free
As it is valve-regulated rechargeable sealed lead acid battery.sealed and glass mat is utilized .acid is trapped inside.
so refilling is not needed and is leak proof.
3. Low self discharge
The self –discharge rate for FOBERRIA Sealed Lead Acid Battery is about 2-3% per month at room .temperature compared with 20-30%
for other common battery systems.
4. Longer service life
Used thick and massive calcium grate ensure that FOBERRIA battery has a longer service life over 10years.
5. High discharge rate
Since the internal resistance is low .the battery can provide high rate of discharge.
6. Wide operation temperature range
VRLA Sealed Lead Acid Battery capacity is rated at 25°C , and will operate from 15°C +50°C when it is fly charged Ambient temperature
is 25°C.Service life will be more efficient under 15’C to 25”C .
| Component | Positive plate | Negative plate | Container | Cover | Separator | Electrolyte | Safety valve | Terminal |
| Raw material | Lead dioxide | Lead | ABS | ABS | AGM | Sulfuric acid | Rubber | Copper |
1. Solar power system(off-grid solar power system, solar street light system, solar garden light system);
2. Wind Power System;
3. UPS and computer backup power;
4. Telecommunication system;
5. Power station System;
6. Railway System;
7. Emergency lighting system;
8. Alarm system for fire protection, security.
| F.V/Time | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h | 8h | 10h | 20h |
| 9.6V | 87.2 | 67.2 | 40.2 | 24.7 | 14.6 | 10.4 | 8.4 | 7.18 | 4.94 | 4.07 | 2.16 |
| 9.9V | 84.6 | 65.6 | 39.4 | 24.3 | 14.5 | 10.3 | 8.36 | 7.14 | 4.91 | 4.06 | 2.15 |
| 10.2V | 81.1 | 63.2 | 38.2 | 23.7 | 14.4 | 10.3 | 8.3 | 7.09 | 4.87 | 4.05 | 2.13 |
| 10.5V | 77.6 | 61 | 37.3 | 23.2 | 14.2 | 10.2 | 8.24 | 7.04 | 4.84 | 4.03 | 2.13 |
| 10.8V | 73.2 | 57.8 | 35.9 | 22.5 | 13.8 | 9.89 | 7.99 | 6.83 | 4.69 | 4 | 2.12 |
> Constant Power Discharge Characteristics(Watt,25ºC)
| F.V/Time | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h | 8h | 10h | 20h |
| 9.60V | 942 | 738 | 451 | 282 | 169 | 122 | 98.8 | 84.9 | 58.6 | 48.6 | 25.9 |
| 9.90V | 914 | 720 | 442 | 278 | 168 | 122 | 98.3 | 84.4 | 58.3 | 48.5 | 25.8 |
| 10.2V | 876 | 694 | 428 | 271 | 167 | 121 | 97.6 | 83.8 | 57.9 | 48.4 | 25.8 |
| 10.5V | 838 | 670 | 418 | 265 | 164 | 120 | 96.9 | 83.2 | 57.5 | 48.1 | 25.6 |
| 10.8V | 791 | 635 | 403 | 257 | 160 | 116 | 94 | 80.7 | 55.8 | 47.8 | 25.4 |
